R420 Side Feeding System Model A & B

This model has been designed to wrap square and rectangular shaped products. Products can be wrapped individually, aligned side by side or vertically in groups. The feeding system can be fixed to another working line. The product sensor will only work as the product arrives. If there is no product, it will wait for the product to arrive and then carry on with its process. Printed and trasparant film material can be used.

Both models A and B operate in the same way, the fact that larger (boxed products) can be wrapped using the B model is the difference between the two machine models.

  Model A Model B
Size of pack Min.
(mm)
Max.
(mm)
Min.
(mm)
Max.
(mm)
Length 60 300 60 300
Width 35 120 35 160
Height 15 70 15 70
Perimeter 140 420 140 440
Capacity 20 - 55 packets / per minute 20 - 55 packets / per minute
Power 4 KVA 400V
AC 3 PHASE
4 KVA 400V
AC 3 PHASE
Weight 900 kg. 900 kg.
